SB-EX-Ran Random Side-belt Case Taper Machine
Eastey's SB-EX Random allows users to run a variety of case sizes without having to manually adjust for each box. The system's unique and simple design has proven to be one of the most reliable case tapers on the market today, keeping production and maintenance efforts to a minimum and providing fast and efficient alternatives to hand taping.
Machine Dimensions:- (L) 46in (1160mm)
- (W) 40.6in (1030mm)
- (H) 61in (1550Dimensions for SBEX Fully Auto
- (L) 46in (1160mm)
- (W) 40.6in (1030mm)
- (H) 61in (1550mmmm
- Top & Bottom Belt Drive
- Minimum Box Size: 5"(L) x 4.5"(W) x 4.5"(H)
* May be able to run smaller boxes with testing - Maximum Box Size: ∞"(L) x 23"(W) x 23"(H)
- Dual 1/4 HP drive motors
- Tape Speed: 30 cases/min
- Belt Speed: 75ft/min
- Power Supply 110 VAC, 60Hz, 6A
or
(866) 520-3248
The SB-EX Random's side belts are great for heavy weight, narrow, or small boxes. It is ideal for void-fill random cases where the packaged product does not support the box. SB-2EX Random is designed to handle boxes that most other case tapers can't.
PRODUCTION MEETS VERSATILITY
SB-2EX Random utilizes easy to load top and bottom tape cartridges and will seal boxes as narrow as 4.5" wide and as low as 4.5" tall. Side rail and tape head height adjustments are made automatically on the fly as soon as the case is presented to the automatic sensors.In addition, the SB-2EX Random comes equipped with a memory function that adjusts to the maximum box depth.This eliminates full travel of the tape head and reduces wear on the machine.
* May be able to run smaller boxes with testing
INDUSTRIAL STRENGTH OPERATION
Dual 1/4 drive motors, aggressive industrial strengthdrive belts, and roller tables make SB-2EX Random a workhorse that will stand up to your toughest challenges. Each case taping machine is made from 12 gauge steel that will withstand even the most rugged applications. A powder coated exterior protects the machine from abusive conditions and guarantees years of use. Best of all, the SB-2EX Random is CE certified, so users can be confident it will consistently provide reliable, high quality case sealing.
CASE TAPING MADE EASY
SB-2EX Random is designed and built with the customer in mind. Top and bottom tape heads are interchangeable and are designed for easy tape threading. These machines accept 2" wide pressure-sensitive tape as a standard, or can be field convertible to 3" tape heads for wider case taping applications. Operators can learn to use Eastey's SB-2EX Random case taping machine in minutes, avoiding breaks in production and downtime, saving your company money and increasing your ROI.
| Power Supply | 110 VAC, 60Hz, 6A |
|---|---|
| Output | Tape Speed: 15-20 cases/min |
| Motor | Dual 1/4 hp drive motors |
| Min Box Size | 5"(L) x 4.5"(W) x 4.5"(H) * May be able to run smaller boxes with testing |
| Max Box Size | ?"(L) x 23"(W) x 23"(H) |
| Drive | Side Belt Drive |
| Capacity | Belt Speed: 75ft/min |
| Warranty | 1 Year Warranty |
